VELTRIX GRINDCORE GC-215
The ergonomic entry point into universal internal cylindrical grinding.
The GC-215 is a CNC universal internal cylindrical grinding machine designed for manufacturers stepping into precision grinding without compromising on accuracy. Built to deliver an excellent price-to-performance ratio, it handles internal, surface, and external grinding operations on a single platform — making it the ideal all-round machine for compressor, hydraulic, machine tool, aerospace, and tooling components. With a maximum workpiece length of roughly 590 mm and a workpiece diameter of up to 445 mm, the GC-215 comfortably covers a wide range of mid-sized components while keeping operator setup fast and intuitive.
Hardware Features
- Grinding spindle turret available with 2.5° Hirth manual or 1° Hirth automatic indexing
- Frequency-controlled belt spindles for external and internal grinding, running up to 65,000 rpm
- Manual control unit positioned close to the grinding process for fast set-up
- Granitan S103 mineral casting machine base for superior thermal and vibration stability
Software Features
- Pictogram-based programming support for simplified operation
- Operator-guided set-up workflow
- Manual grinding cycle for single workpiece seats
- Short set-up and changeover times via QuickSet with automatic grinding spindle turret
Technical Data — GC-215
| Specification | Veltrix Published Value |
|---|---|
| Max. Travel X | 300 mm (11.81 in) |
| Max. Travel Speed X | 10,500 mm/min (413 in/min) |
| Max. Travel Z | 860 mm (33.86 in) |
| Max. Travel Speed Z | 20,600 mm/min (811 in/min) |
| Max. Spindle Power | 7.1 kW (9.5 hp) |
| Max. Number of Revolutions | 65,300 rpm |
| Max. Grinding Wheel Diameter | 415 mm (16.34 in) |
| Max. Grinding Wheel Width | 43 mm (1.69 in) |
| Swiveling Range B | -13° to +193° |
| Swiveling Range C | ∞ (continuous) |
| Workpiece Length | 590 mm (23.23 in) |
| Workpiece Diameter | 445 mm (17.52 in) |
| Center Height | 245 mm (9.65 in) |
Detailed technical specifications can be provided upon request. Specifications and features are subject to change without prior notice. Optional accessories and special configurations can be offered on request. Final specifications and scope of supply shall be as confirmed in our techno-commercial offer. Minor customization can be offered based on customer requirements and technical feasibility.
